INSTRUMENT/CONTROLS
OPERATING CONTROLS Control Switches
2 5 1
4 3
1. STARTER KEY SWITCH The starter key switch can be removed in the OFF position. Three switch positions are as follows: Position (OFF) Engine and all lamps except the turn signal and flasher lamps are turned off. Position (HEAT) & (ON) First position clockwise from OFF. In this position (Engine not running) energizes the glow plugs. The charge indicator, glow plug indicator and oil pressure indicator will illuminate. The fuel gauge and temperature gauge will show correct values. Position (START) Turn the key fully clockwise against the force of the spring in the switch. The starter motor will turn the engine. Release the key immediately when the engine starts.
NOTE: To prevent operation by persons not authorized and the possible discharge of the
battery, remove the starter key when you leave the tractor.
IMPORTANT: Do not keep the starter key switch in the ON position for a long time when the tractor is not operating.
23
