LUBRICATION/FILTERS/FLUIDS
Transmission Oil Change Oil Change Interval…………………………………………………………………… Every 200 hours To change the transmission oil, use the following procedure: 1. Put the tractor on level ground, apply the park brake and stop the engine. Move the range shift lever to L position. 2. Remove the drain plugs from the transmission case. (3 pieces)
NOTE: For best results, drain the oil when the
TRANSMISSION DRAIN PLUG
oil is warm.
3. Replace the hydraulic filter. See Hydraulic Filter in this manual. 4. For the hydrostatic drive tractor, replace hydrostatic filter if needed, See Hydrostatic Filter (Hydrostatic Drive) in this manual. FILL HOLE
5. Install the drain plugs with a seal washer and tighten to a torque of 39 to 44 N-m (29 to 33 Lbft).
[ GEAR DRIVE ]
6. Add the recommended oil through the fill hole and check the oil level. 7. Start the engine and check for leaks. 8. Recheck the oil level after stopping the engine. If the oil level is low, add oil up to the specified level.
FILL HOLE
[ HYDROSTATIC DRIVE ]
102
