Cooling system Adding Coolant to the System Always ensure that the cooling system is free from any leakage. The coolant level shall be checked at the recovery bottle (C) if there is no coolant leakage in the cooling system. Top-up coolant in the recovery bottle as per level indicator marks on the recovery bottle. It is however essential to check the coolant level in Radiator if coolant leakage is observed from any point in the cooling system. To check coolant level in radiator, proceed as follows : 1. Allow the engine to cool and open the hood. 2. Remove the radiator cap (A). 3. Top-up coolant in the radiator from fill neck (B) with clean coolant. 4. Start the engine and let it idle for some time to remove the engine air from the system. Coolant level in radiator will reduce. 5. Slowly pour coolant into the radiator till the coolant level in the radiator does not go down further.
60 Model 25 25 4WD OPM/Sep-07
A
B
C
