Instrument cluster RPM Meter This meter gives the number of revolution per minute of the engine. To arrive at the RPM value at any given point of time while the engine is in operation, multiply the pointer reading by 100. Example : If the reading shows 15, The actual engine RPM value = 15 x 100 = 1500. Hour Counter The Hour counter is located in the RPM meter. It is operated by signal from alternator when the engine is running. Hour counter displays the cumulative engine running hours. Fuel Gauge The Fuel Gauge indicates quantity of fuel available in the fuel tank. The indication is divided into three stages Viz. Empty, Half and Full. The RED zone of this gauge starts when the fuel level in the fuel tank reduces below 2.62 US gallon ( 9.93 lit )
Water Temperature Gauge This gauge indicates coolant temperature of the engine. When the pointer lies in RED band : 1. It indicates excessive engine coolant temperature. 2. Get the cause identified. 3. Further engine operation should be done only after elimination of the problem.
Engine Oil Pressure gauge This gauge records the engine oil pressure while engine is operating. When the pointer lies in RED band : 1. It indicates low engine oil pressure. 2. Get the cause identified. 3. Further engine operation should be done only after elimination of the problem.
28 Model 25 25 4WD OPM/Sep-07
