5-12 Upper Swing Body: Remote Control Valve 3 Removal and Installation of Travel Remote Control Valve Assembly Warning
• Be sure to release the hydraulic pressure before beginning work.
Caution
• Be sure to stop the engine before beginning work.
Items to prepare • • • • • • • •
Wrench (17 mm, 19 mm) Hexagon wrench (8 mm) Phillips screwdriver Marking pen Caps Plugs Rags Cleaning fluid
[1]
Use the screwdriver to remove the 3 screws (1), and then remove the cover (2).
2
1
[2]
Remove the floor mat (1).
1
423
