Control and operation
Operating manual
Operating and control elements
Menu "Check" With the menu "Check", you can see the value of different parameters and specified inputs/outputs of the machine. Push the "Check" button to access to this menu from the main screen. Menu "Info" With the menu "Info", you can see different technical data and working times of specified parts of the machine. Push the "Info" button to access to this menu from the main screen. Menu "Settings" With the menu "Settings", you can set specified parameters of the machine. Push the "Settings" button to access to this menu from the main screen.
Select a submenu From each monitoring menu:
Push the "Up" and "Down" buttons to select the necessary submenu.
Push the "Accept" button to access to the selected submenu.
Return to the monitoring menu From each submenu:
Push the "Return" button to go back to the related monitoring menu.
Menu "Diag" When an error occurs on the machine, the symbol of the menu "Diag" flashes red on the main screen. This symbol continues to flash until there are errors not acknowledged or not rectified.
