Control and operation
Operating manual
The access and the outfit of the cab
For maintenance intervals, refer to the control and maintenance chart. Replace damaged mirrors and cameras immediately. To cover the correct area: Set the cameras and adjust the outside mirrors so as to be able to see a person standing out of the hatched area defined by the four checkpoints given on the fig. above.
3.2.11
Lighting Regularly check lighting devices for condition. If necessary: ice to get access to them. For maintenance intervals, refer to the control and maintenance chart.
copyright © Liebherr-Mining Equipment Colmar SAS 2020
3 - 58
MJFCIFSS
R 9200 E / 14417782
