VI. TRANSPORTING NOTE: It is not recommended that the detasseler be towed, but if it should ever be necessary, follow these steps carefully:
C. TOWING 1. Fold the outriggers in and lock them to the detasseler. 2. Disengage each Torque Hub® by removing two outer cap bolts, turning the outer cap with the extended center in towards the hub and reinstalling the two outer cap bolts. This process pushes on a spring-loaded splined shaft, disengaging the Torque Hub ® (fig. 6.3).
FIG 6.3
NOTE: Wheel motors will be damaged if these steps are not taken.
When re-engaging Torque Hubs®, make sure springloaded splined shaft has returned to its extended position.
TOWING CONTINUED
