V. OPERATING INFORMATION CAB OPERATION CONTINUED
STEERING COLUMN To adjust the HAGIE 204’s steering column for driver comfort or to ease cab exit and entry, locate the tilt lock lever in the center of the column (fig. 5.49). Push down on the lever to release the lock (fig. 5.50). Pull or push the column to the desired position and release the lever to re-lock the steering column.
FUEL TANK SELECTOR To draw engine fuel from the right fuel tank, depress the fuel FIG 5.49
selector switch (fig. 5.52) to the “RIGHT” position. To switch to the left tank, depress the fuel selector switch to the “LEFT” position. You may operate from either tank until the “YELLOW” low level indicator light illuminates. Then you must either switch to the other tank or refuel.
FIG 5.50
FIG 5.52
CAB OPERATION CONTINUED FIG 5.51
