V. OPERATING INFORMATION SPEEDOMETER/TACHOMETER CONTINUED
Speedometer/Tachometer Display Screen Quick Reference Chart KEY-ON DISPLAY FOR 1 SEC.
MPH POWER-UP DISPLAY
RPM POWER-UP DISPLAY
OR
Hold down the left (RPM) button until the display with four “8’s” appears, then release and parameter setting will appear.
Press RPM button to increase setting; value will be saved if no button is pushed for 5 seconds.
Hold down both buttons until the display with four “8’s” appears, then release and parameter setting will appear.
Press MPH button to decrease setting; value will be saved if no button is pushed for 5 seconds.
Press RPM button to scroll through miscellaneous parameters settings: P3 = power-up display P4 = signal tracking speed P5 = input device
Hold down the right (MPH) button until the display with four “8’s” appears, then release and parameter setting will appear.
Press RPM button to increase setting; value will be saved if no button is pushed for 5 seconds.
Press MPH button to decrease setting; value will be saved if no button is pushed for 5 seconds.
Press MPH button to change setting of displayed parameter (0 or 1); P3 may be 0 or 1 (0 displays RPM on power-up and 1 displays MPH on power-up); P4 should be set to 1: P5 should be
