V. OPERATING INFORMATION OPERATING THE ENGINE Pre-operational Checks
Page Reference
1. Check the engine oil level. Do not operate the engine when oil is below the low mark on dipstick.
87
2. Check the coolant level in the radiator and the coolant overflow reservoir.
89-90
3. Check the hydraulic oil reservoir level.
87
4. Check cooling air intake screens.
93
5. Check engine drive belt.
106-107
6. Drain fuel/water separator (diesel only).
97
7. Check the Filter Minder ® (diesel only).
94
8. Check for any oil or fuel leaks and correct if needed.
Starting the Engine
Start engine from operator’s seat only. When running engine in a building, be sure there is adequate ventilation.
1. Position hydrostatic control lever to “N” (neutral) position. 2. Apply parking brake (see page 70). When starting procedure is complete, release parking brake before moving. 3. Start the engine with the throttle at one-half speed. 4. Turn key to the “ON” position to check instruments.
