Technical Information KPP Pulse Pickup (PPU)
Installation Diagrams
Pulse Pickup Installation
Gap
11/16 hex wrench
To after adjustment Magnetic speed ring
Hold sensor in position while tightening locknut
Speed sensor
12,7 [0.50] Flats 22°
t]
Shaft cernterline 22°
12,7 [0.50] Flats 22°
22° Shaft cernterline
Sensor with Turck Eurofast connector
Sensor with Packard connector
2055A
Directional Conical End Models, Series 51 and 51-1 Cartridge Motors Only
180° ± 15°
Orientation notch Speed sensor
16
250 - 213
11029257
2052A
