IV. PREPARING TO OPERATE ATTACHING EQUIPMENT CONTINUED

Attaching Lift Assemblies

2

1

FIG 4.13 Refer to 204 DETASSELER Parts Manual for correct hardware when following these steps: 1. Attach the lift mounts (fig. 4.13, item 2) to the tool bar and outriggers at the appropriate spacings.

2. Attach the lift arms (fig. 4.13, item 1) to the lift mounts.

3. Attach the lift arm cylinders to the lift arm as2

semblies (fig. 4.14, item 2).

4. Attach the tool bar weldment to the lift arm assemblies (fig. 4.14, item 1).

5. Connect hydraulic hoses to lift cylinders. Refer to 204 DETASSELER Parts Manual for correct hydraulic schematics.

1

FIG 4.14

ATTACHING EQUIPMENT CONTINUED
