Series 90 Axial Piston Pumps Technical Information Control options NON FEEDBACK PROPORTIONAL ELECTRIC CONTROL (NFPE)
The Non Feedback Proportional Electric (NFPE) control is an electrical automotive control in which an electrical input signal activates one of two proportional solenoids that port charge pressure to either side of the pump servo cylinder. The NFPE control has no mechanical feedback mechanism. The pump displacement is proportional to the solenoid signal current, but it also depends upon pump input speed and system pressure. This characteristic also provides a power limiting function by reducing the pump swashplate angle as system pressure increases. A typical response characteristic is shown in the accompanying graph.
Resistance Table Supply Voltage
Coil Resistance
12 V
5.4 Ohms
24 V
21.6 Ohms
NFPE Schematic M6
M5
M3
M4
M1
A
M2
B L1
S
L2 P003 174
32
250 - 137
520L0603 • Rev FB • July 2007
