Series 90 Axial Piston Pumps Technical Information System design parameters SHAFT LOADS
Normal bearing life in B10 hours is shown in the table below. The figures reflect a continuous differential pressure of 240 bar [3500 psi], 1800 min-1 (rpm) shaft speed, maximum displacement, and no external shaft side load. The data is based on a 50% forward, 50% reverse duty cycle, standard charge pump size, and standard charge pressure. Bearing life Frame size Bearing life – B hrs Series 90 pumps are designed with 42 18 060 bearings that can accept external radial 55 22 090 and thrust loads. The external radial 75 22 970 shaft load limits are a function of the 100 22 670 load position and orientation, and the 130 17 990 operating conditions of the unit. 10
The maximum allowable radial load (Re), is based on the maximum external moment (Me), and the distance (L) from the mounting flange to the load. It may be determined using the table and formula below. Thrust (axial) load limits are also shown.
180
16 150
250
12 020
Radial and thrust load position L 0˚Re Re 270˚ Re Tout Tin
90˚ Re
Re = Me / L 180˚Re
Pump swashplate
P104 292E All external shaft loads affect bearing life. In applications with external shaft loads, minimize the impact by positioning the load at 90° or 270° as shown in the figure.
Contact your Sauer-Danfoss representative for an evaluation of unit bearing life if: • continuously applied external loads exceed 25 % of the maximum allowable radial load (Re). • the pump swashplate is positioned on one side of center all or most of the time. • the unit bearing life (B10) is critical. Sauer-Danfoss recommends tapered input shafts or clamp-type couplings for applications with radial shaft loads. Allowable external shaft load
14
250 - 119
Parameter External moment (Me)
042 126
055 101
075 118
100 126
130 140
180 161
250 176
N•m [lbf•in] Maximum shaft thrust in (Tin)
[1114] 2635
[893] 3340
[1043] 4300
[1114] 5160
[1238] 5270
[1424] 7000
[1556] 7826
N [lbf] Maximum shaft thrust out (Tout)
[592] 1020
[750] 910
[996] 930
[1160] 1000
[1184] 688
[1573] 1180
[1759] 1693
N [lbf]
[229]
[204]
[209]
[224]
[154]
[265]
[380]
520L0603 • Rev FB • July 2007
