VII. SERVICE AND MAINTENANCE DRIVE TRAIN Hydrostatic Pump NEUTRAL SETTING - When the hydrostatic lever is in the neutral position, the machine should not be moving in either direction. If it does, the neutral setting of the lever (fig. 7.59) on the hydrostatic pump needs to be adjusted. See accompanying pump manual. CHECK CHARGE PRESSURE - See page 46. REPAIR/REPLACEMENT - See pump handbook accompanying
this
operator’s
manual.
Hydrostatic
pumps are available as a core exchange item from Hagie Manufacturing Customer Support Department.
FIG 7.59
Auxiliary Gear Pumps REPAIR/REPLACEMENT - See pump handbook accompanying this operator’s manual. Gear pumps are available from the Hagie Manufacturing Customer Support Department.
Torque Hub®
Wheel Motors REPAIR/REPLACEMENT
-
See
wheel
motor
handbook accompanying this operator’s manual. Wheel motors are available as a core exchange item from Hagie Manufacturing Customer Support Department.
Torque Hubs® GREASE - Grease according to page 99. OIL - Maintain oil level according to page 87. Wheel Motor FIG 7.60
REPAIR/REPLACEMENT
-
See Torque
manual accompanying this operator‘s manual.
Hub®
