VII. SERVICE AND MAINTENANCE FUSES CONTINUED
Depth Command Fuse The fuse for the DEPTH COMMAND is located in the switch box (fig. 7.47). If the DEPTH COMMAND fuse blows, remove it by rotating the fuse cap counter-clockwise as you push in. Then pull the fuse straight out. Replace the blown fuse with the same amperage fuse FIG 7.47
only (fig. 7.48). Operating more than two actuators at one time may cause the fuse to blow (see page 63). A blown fuse may indicate that the LS/DEPTH COMMAND pivot bolts (fig. 7.49) are torqued too tight. If the fuse continues to blow, determine cause and correct it.
FIG 7.48
ELECTRICAL CONTINUED FIG 7.49
