Working Range Limiter 1.4 Operation of the Working Range Limiter
1.4.3
Submenu for slewing angle limit In the Slewing angle limit submenu, the maximum permissible slewing angle of the superstructure can be set.
Opening the submenu
ä
• Press the Slewing angle limit button once. The display switches to the submenu Slewing angle limit. The words ANGLE LIMITATION appear in the top line.
ANGLE LIMITATION
Angle: A: –10.2° B: [OFF] [EDIT]
32.9° 37.9°
The current angle of the superstructure in relation to the carrier (e.g. 32.9°) is displayed in the second line. The most recently saved shutdown values for the slewing angle limit are shown in the third line (e.g. A: –10.2° B: 37.9°). The options in the fourth line are described in the following sections.
Definition of angles A displayed angle of 0° means that the superstructure is turned toward the rear (and is therefore in working position 0° to the rear). Complete rotation out of this working position is divided into two semicircles for the display: – angles in right semicircle are displayed as positive numbers (0° to +180.0°), – angles in left semicircle are displayed as negative numbers (0° to –179.9°).
