Working Range Limiter 1.4 Operation of the Working Range Limiter
1.4.1
Submenu for maximum overall height In the Maximum overall height submenu, the maximum permissible overall height of the boom can be set.
Opening the submenu
@
• Press the Maximum overall height button in the Main menu once. The display switches to the submenu Maximum overall height. The words HEIGHT LIMITATION appear in the top line. The current overall height (height) of the boom (e.g. 23.4 m) is shown in the second line.
HEIGHT LIMITATION Height: 23.4 m Limit: 17.5 m [OFF] [EDIT]
In the third line following the word "Limit", the most recently saved shutdown value for the maximum permissible overall height (e.g. 17.5 m) is shown. The options in the fourth line are described in the following paragraphs.
There are two possible ways to enter the maximum permissible overall height for the Working Range Limiter: – Move the boom to the maximum permissible overall height and apply this value for the Working Range Limiter; p. 1 - 10. – Enter the maximum permissible overall height as a numerical value if the shutdown values are known; p. 1 - 11.
à
à
10.04.2002
H H
When the monitoring function is switched on, you cannot move the boom to a larger shutdown value because the monitoring function will switch off crane movement.
You can exit the subsequent entry mode at any time by pressing the ton once.
ö but-
s Operating instructions Working Range Limiter
2 084 669 en
1-9
