RT800E OPERATOR MANUAL
Lubrication Accessing Boom Lubrication Points Refer to the information in Table 5-1 and next to item numbers 74 - 78 in the lubrication table, which begins on page 5-22, to lubricate the boom. Table 5-1Boom Lubrication Points
Boom Length (ft) (± 0.2 ft)
Item
Boom Section
Access Location
Boom Mode
74
Inner
Large hole in center & outer mid
A
94.6
74
Inner
Large hole in inner mid
B
81.2
75
Outer mid & fly
Small holes on the sides
A
Multiple Lengths
75
Inner mid
Small holes on the sides
B
Multiple Lengths
75
Center mid
Small holes on the sides
B
Multiple Lengths
76
Center, outer mid & fly
External on the boom
A
114
76
Inner mid
External on the boom
B
83.3
77
Extend cable sheaves
Small hole left side on the front of the outer mid
A
79.7
78
Retract cable sheaves
Small holes at the middle of the center mid
A
98.3
5-32
Published 04-05-2017 Control # 307-08
