RT800E OPERATOR MANUAL
SET-UP AND INSTALLATION
Electrical Connection at the Boom Extension Inserts
There is a plug socket (1) at the front of each 16 ft (4.9 m) section (Figure 4-85).
The following describes the electrical connections at the 16 ft sections. Establish the electrical connection at the bi-fold swingaway lattice extension per the following procedures
Transport Condition of the Connection For transport, bring the electrical connections always into the following condition. There is a cable with a plug (3) at the rear of the 16 ft sections (Figure 4-84). For transport, the cable is wound around the holders (1) and the plug is inserted in the dummy socket (2).
For transport, the sockets are covered with protective caps.
At the 72 ft (22.0 m) Boom Extension Establishing a Connection •
Connect the cable of the 33 ft (10.1 m) section to the socket of the second 16 ft (4.9 m) section at the front.
•
Connect the cable of the 16 ft (4.9 m) section to the socket at the main boom.
Disconnecting •
Detach the electrical connection between 33 ft (10.1 m) and 16 ft (4.9 m) section.
•
Detach the electrical connection between 16 ft (4.9 m) section and main boom head.
•
Prepare the electrical connections at the 33 ft (10.1 m) section for transport.
At the 89 ft (27.1 m) Boom Extension Establishing a Connection
3
2
•
Connect the cable of the 33 ft (10.1 m) section to the socket of the second 16 ft (4.9 m) section at the front.
•
Connect the cable of the second 16 ft (4.9 m) section to the socket of the first 16 ft (4.9 m) section at the front.
•
Connect the cable of the first 16 ft (4.9 m) section to the socket at the main boom head.
1
Disconnecting w3367a
FIGURE 4-84
•
Detach the electrical connection between the 33 ft (10.1 m) and front 16 ft (4.9 m) section.
•
Detach the electrical connection between the two 16 ft (4.9 m) sections.
•
Detach the electrical connection between the rear 16 ft (4.9 m) section and the main boom head.
•
Prepare the electrical connections at the 16 ft (4.9 m) section for transport.
•
Prepare the electrical connections at the 33 ft (10.1 m) section for transport.
Unfolding/Folding the Deflection Sheave on the 16 ft (4.9 m) Section 1
This section describes only the unfolding and folding of the deflection sheave on the 16 ft (4.9 m) section. w3368a
FIGURE 4-85
For work with the boom extension, you must fold out the deflection sheaves on the rear 16 ft (4.9 m) section. Fold the deflection sheave for transport.
Grove
Published 04-05-2017 Control # 307-08
4-39
4
