Two-stage swing-away lattice extension 3.6 Description of rigging work
Lowering
• Insert the locking pin for the 12.5 m (41 ft) section in position Released;
à p. 3 - 58.
• Lower the lattice extension until the retaining mandrel (2) is fully out of the holder (1) on the main boom.
Raising
• Raise the lattice extension until the retaining mandrel (2) is fully in the holder (1) on the main boom.
• Insert the locking pin for the 12.5 m (41 ft)
à p. 3 - 58.
