Two-stage swing-away lattice extension 3.4 Slinging points
Slinging points for the 12.5 m (41 ft) section alone
• Sling the 12.5 m (41 ft) section alone onto the two slinging points (4) and (5) so that it is in the centre of gravity.
• Guide the sling rope from outside around the struts onto the slinging points to prevent tipping to the side.
Slinging points for 22 m (72 ft) two-stage swing-away lattice extension, 9 m (30 ft) section folded at the side
• Sling the folded 22 m (72 ft) two-stage swing-away lattice extension only onto the two slinging points (3) and (5) so that it is in the centre of gravity.
• Guide the rope at point (5) from inside and at point (3) from outside around the strut of the 12.5 m (41 ft) section onto the slinging points to prevent tipping to the side. Slinging points for 22 m (72 ft) two-stage swing-away lattice extension, 9 m (30 ft) section swung-out
• Sling the rigged 22 m (72 ft) two-stage swing-away lattice extension only onto the two slinging points (1) and (2) so that it is in the centre of gravity.
• Guide the sling rope from outside around
04.08.2004
the struts onto the slinging points to prevent tipping to the side.
