Two-stage swing-away lattice extension 3.1 Operating and display elements
Righthand control lever Raise lattice extension:
Control lever to the left
Lower lattice extension:
Control lever to the right
Operating elements of the SLI Status display for length of lattice extension with a membrane button
1&0
Displays the length of the lattice extension in (feet). The status display is activated when an SLI code for working with the lattice extension is entered in the Rigging mode status display. The displayed length is obtained from the entered SLI code. If the Rigging mode display of the entry mode is switched on, pressing the membrane switch repeatedly displays other values which are permitted according to the Lifting capacity table. When the greatest length is reached and the membrane switch is pressed again, the display starts again at the beginning with the lowest value. Status display for angle of lattice extension with membrane switch
1&0
Displays the current measured angle of lattice extension to the main boom in degrees. The status display is activated when an SLI code for working with the lattice extension is entered in the Rigging mode status display. No values can be selected on the display.
H
Membrane button with indicator lamp for height of single-sheave boom top After pressing the switch, the green indicator lamp in the switch lights up and the current height of the single-sheave boom top of the main boom or the lattice extension is shown in (feet) in the Information status display.
348
3-2
Membrane switch with indicator lamp for angle of lattice extension After pressing the switch, the green indicator lamp in the switch lights up and the current angle of the lattice extension, in relation to the horizontal is shown in the status display Information. Information Display Displays corresponding values upon pressing the membrane switch Single-sheave boom top height or Angle of the lattice extension.
2 084 906 en
Operating instructions lattice extension GMK 5200/6220-L
04.08.2004
K
