Auxiliary single-sheave boom top 5.1 Identification
5
Auxiliary single-sheave boom top
5.1
Identification
S H
For technical reasons a truck crane may only be set with one auxiliary single-sheave boom top. If you wish to use the auxiliary single-sheave boom top on several GROVE truck cranes, the auxiliary single-sheave boom top needs to be adapted to the relevant cranes and marked with all the serial numbers. Danger of damage if the auxiliary single-sheave boom top has not been adjusted or if it has been incorrectly adjusted. The auxiliary single-sheave boom top should only be adjusted by your local GROVE Customer Service! The serial number can be found on the front (1) of the auxiliary single-sheave boom top.
04.08.2004
S
Danger of malfunction and damage! Operate the truck crane only with the auxiliary single-sheave boom top that has the same serial number as the crane. The SLI is only set for this auxiliary single-sheave boom top. This prevents malfunctions and damage.
Operating instructions lattice extension GMK 5200/6220-L
2 084 906 en
5-1
