7. Maintenance
Maintenance table Initial 100 Hours Service 1. Transmission
2. Hydraulic System
1.1. Change oil 20* Replace filter element 21* Clean strainer 22*, at least once a year 2.1.Replace hydraulic return filter element 43*. 2.2.Replace hydraulic high pressure filter element 43a*.
162
1.1.Check/adjust PDE injector rocker arms 2.1.Run the AEB-Tester 3.1.Change oil 32*
166 166 168
164 165
Initial 500 Hours Service 1. Engine 2. Transmission 3. Tandem housings 8 Hours / Daily Service 1. General 2.
3. 4. 5. 6.
7. 8. 9.
1.1.Walk around check, before start 169 1.2.Check driver's seat, before start 169 Engine 2.1.General condition check - look for leakages remedy as necessary 170 2.2.Drain the water separating fuel filter 4* 170 2.3.Check oil level, before start 1* 171 2.4.Check coolant level, before start 5* 171 2.5.Check fuel level, before start 13* 172 2.6.Function check of the centrifugal cleaner, after operation 2* 172 Transmission 3.1.Check oil level, before operation 20* 173 Hydraulic system 4.1.Check oil level, before start 40* 174 Lubrication 5.1.Door and fender hatches, 8 lubricators 57* 175 5.2. Cab rear hinges, 2 lubricator 58 * 176 Brake system 6.1.Parking brake check braking (holding) capacity, before operation 176 6.2.Service brake (main brake) check braking (holding) capacity, before operation 176 6.3.Service brake (main brake) check function, before operation 177 6.4.Accumulators check the oil pressure, before operation 177 Steering 7.1.Check function, before operation 178 Engine brake 8.1.Check function, before operation 178 Engine/retarder brake 9.1.Check function, before operation 178
40 Hours / Weekly Service 1. Cab ventilation
1.1.Clean prefilter 70* 1.2.Air conditioner system 2.1.Check tyre pressures, before operation 3.1.Check the lubricant level in the reservoir.
2. Tyres 3. Automatic central lubrication (Lincoln lubrication system)3 3. Automatic central 3.1.Check the grease level in the reservoir. lubrication (Grovenveld lubrication system)
179 179 180 180
181
500 Hours Service 1. Engine
1.1.Change oil 1* 1.2.Clean centrifugal cleaner 2* 1.3.Replace oil filter 3* 1.4.External cleaning of the radiator, at least once a year 5*
182 183 186 187
* Numbers refer to positions on the lubrication schedule, chapter 6 Operating & Maintenance Manual
139
