How to operate the feeder breaker —
Start conveyor motor in forward direction To start the conveyor motor in forward position, proceed as follows: e2r Turn the "MAN/AUTO" selector switch located on the control console (Fig. 35) to either the "AUTO" (belt sequence) or the "MAN" position (no belt sequence). Turn the "LOCAL/REMOTE" selector switch located on the control console to the "LOCAL" position (Fig. 35). ®' Turn the "FWD/REV" selector switch located on the control console to the "FWD" position (Fig. 35). IMPORTANT! The tram/breaker motor must be running to start conveyor in the forward direction.
Fig. 35: Start conveyor controls (Forward direction)
"START CONVEYOR"
A6474X236
VSVE/01
5.31
