BI010575 8750 Walking Dragline
BOARDING STAIRS Access to the main frame and machinery house can be attained by using the boarding stairs located on the right and left sides of the machine. When lowered, the stairs allow boarding from ground level. These stairs must be in their raised and latched position to enable the operator’s controls.
Right Side Boarding Stairs
When lowered, the stairs allow entrance to the base frame and machinery house from ground level. To lower the stairs, press and hold the DOWN pushbutton on the control panel. The stairway will return to ground. To raise the stairs, press and hold the UP pushbutton. Release the button to stop motion. NOTE: The stairs must be in the RAISED position to enable the operator’s controls.
