OPERATOR CONTROLS DANGER:
DO NOT ATTEMPT TO OPERATE THIS MACHINE UNLESS YOU UNDERSTAND ALL THE MACHINE CONTROLS. NEVER LEAVE THE OPERATOR’S SEAT WITHOUT FIRST SETTING ALL MOTION BRAKES AND “DROPPING OUT” (DE-ENERGIZING) LINE EXCITATION BY PUSHING THE CONTROL STOP PUSHBUTTON.
The operating controls for this machine are grouped around or are part of the consoles on the operator’s seat in the cab. The machine startup controls are located inside the machinery house. The operator’s seat has adjustments for operator comfort and control. Position it to the best location before taking over the controls. See the seat adjustment procedure following later in this section.
Operating Controls
The Display Screen is shown mounted to the right arm of the seat; it can be installed on the left arm as well. Manual No. 10863
