BOOM SUPPORT ROPES Boom support ropes stretch from the tri-structure to the boom point, holding the boom in proper alignment. Four spacers are used to maintain separation of the Boom Support Ropes.
Boom Support Ropes
BOOM CLUSTER IDENTIFICATION Each structural member on the boom can be identified by a boom cluster identification. Numbers are painted on the boom structure. Each identification contains a letter code and number. The letter codes are listed below. Numbers increase from the boom foot pivot (location 1) to the boom point (location 30). CODE RT RB LT LB CT CB CRT CRB CLT CLB CM
March 2011
LOCATION RIGHT HAND TOP RIGHT HAND BOTTOM LEFT HAND TOP LEFT HAND BOTTOM CENTER TOP CENTER BOTTOM CENTER RIGHT HAND TOP CENTER RIGHT HAND BOTTOM CENTER LEFT HAND TOP CENTER LEFT HAND BOTTOM CENTER MIDDLE
