Installation __________________________________________________ Opening the block-type connector: Drive out the roll pin(s). Push the block connector halves in the direction of the arrows. The block connector is open. Closing the block connector: Push the block connector halves together opposite the direction of the arrow. Drive in the roll pin(s). The block connector is closed.
Please keep in mind that dimension b of the flat-type connectors is larger than dimension b of the respective round steel link chain according to DIN 22252. Therefore, make sure to check the passage dimension of vertically installed flat-type connectors, e.g. in the bottom race of the conveyor. Also observe the position of the chain link in the flight. Flat-type connectors are not allowed to be installed vertically in conveyors with flat link chains according to DIN 22255.
________________________________________________________________ 4.24 VUSS / 00 ________________________ BUCYRUS – AFC ©
© BUCYRUS 2011
Flat-type connector The flat-type connector can be installed in horizontal and vertical position.
