__________________________________________________ Installation Directing bracket The directing bracket is only used on the head-end drive of a face conveyor system. It serves to redirect the conveying flow at right angles onto the subsequent conveyor unit. The directing bracket is positioned onto the drive frame and screwed down onto it in accordance with the hole pattern. stripper bracket
The screwed down strips for the stripper blade (2) can be changed when necessary (see chapter 5, section “Replacement of wear parts”).
Stripper bracket picture
© BUCYRUS 2011
NEED NEW DRAWING Directing bracket 1—directing bracket, LI 2—stripper blade 4—screw-down strip 5—screw down angle 6—bolt [hh] 7—threaded plate
8—bolt [hh] 9—bolt [hh] 10—bolt [hh] 11—nut [lock] 14—cable holder
