ADJUSTMENT/MAINTENANCE
DRIVE BELT SERVICE SPECIFICATIONS
A24666
The drive belt for the engine cooling fan is adjusted by an automatic tension pulley. It is not necessary to check the tension with a tension gauge.
REPLACING THE DRIVE BELT Replace the drive belt if you see any of the following: cuts, cracks, loose cords, grease, oil, or twisting. 1. Install a 1/2 inch breaker bar in the bracket for the tension pulley. 2. Use the breaker bar to move and hold the tension pulley away from the drive belt. 3. Remove the drive belt. 4. Install the new drive belt. 5. Release the tension pulley. 6. Remove the breaker bar.
183
TRIM THIS EDGE RIGHT PAGE Bur 6-25930
TRIM THIS EDGE
TENSION CHECK
