LUBRICATION Remove and discard the used filter (4). Install a new element, making sure the seal (5) is facing upwards. Install the cover (3) and the nut (2) correctly.
Replace the suction filter and the return filter. See “Cleaning and replacement of the suction filter” and “Return filter replacement”. Install the reservoir drain plug. Put new hydraulic fluid into the reservoir. See “Filling the reservoir”.
REPLACING THE HYDRAULIC FLUID
Install the reservoir cover plate and seal.
Release all pressure in the hydraulic reservoir. See “Releasing pressure in the hydraulic system”.
IMPORTANT: Before you start the engine, it is very important that you bleed air from all the hydraulic components. See “Bleeding air from the hydraulic components”. Start and run the engine with no load for approximately five minutes.
TRIM THIS EDGE
Move each control slowly several times to remove any air in the system. Swing the upperstructure evenly left to right two turns or more. Place the machine in position and then stop the engine.
CD00E176
Remove the reservoir cover plate. Using a pump, remove the fluid from the hydraulic reservoir. Have a container with a suitable capacity ready.
Check the oil level in the hydraulic reservoir and add oil as required and check that there are no air bubbles in the hydraulic reservoir.
CD00E113
Remove the drain plug to remove the remaining fluid from the reservoir.
