LUBRICATION
LEVEL IN RESERVOIR FILLING THE RESERVOIR
STEP 1
Release all pressure in the hydraulic reservoir. See “Releasing pressure in the hydraulic system”.
CS98N547
Place the machine on flat, level ground and place the attachment in the position shown. Stop the engine and remove the starter switch key. STEP 2
BD00M221
The oil should be in the middle of the indicator. Add more oil if necessary. See “Filling the reservoir”.
159
TRIM THIS EDGE RIGHT PAGE Bur 6-25930
TRIM THIS EDGE
CD00E112
Clean the cover plate and the area around the plate. Remove the cover plate and add hydraulic fluid to the reservoir as required. Replace the cover plate seal if required and install the cover plate.
