LUBRICATION
HYDRAULIC FLUID CHART Use only hydraulic oils meeting Case specifications or equivalent AW (anti-wear) hydraulic oils. Temperature Fahrenheit
−30° −20° −10° 0° 10° 20° 30° 40° 50° 60° 70° 80° 90° 100° 110° 120° MS-1216 GRADE ISO VG 46 MS-1210 TCH MS-1230 GRADE NT MS-1230 GRADE LT −34° −29° −23° −18° −12° −7° −1° 4° 10° 16° 21° 27° 32° 38° 43×° 49° Temperature Celsius NOTE: Case specification MS-1210 TCH Fluid is used in place of ISO VG 32 (−5 to +65F) and ISO VG 46 (+10 to +90 F).
TRIM THIS EDGE
Case specifications MS-1230 Grade NT or Grade LT is used in place of SO VG 32 (−5 to +65F), ISO VG 46 (+10 to +90 F), ISO VG 100 (+30 to +115 F), and MS-1210 TCH.
!
!
!
WARNING: Before carrying out any service work on the hydraulic system it is necessary to allow it to cool down (the temperature should not be more than 40 degrees C (104 degrees F).
WARNING: Hydraulic fluid or grease injected into your skin can cause severe injury or death. Keep your hands and body away from any pressurized leak. Use cardboard or paper to check for a leak. If fluid is injected into your skin, see a doctor immediately and have the fluid removed. WARNING: Before carrying out any service work on hydraulic filters or the hydraulic system, remove the hydraulic reservoir breather cap and press the button on the breather to release all pressure in the system. Failure to observe these instructions can cause injury. See “Releasing pressure in the hydraulic system”.
158
