OPERATING INSTRUCTIONS
MACHINE IN TRANSPORT POSITION
A
B TRIM THIS EDGE
B9410161
NOTE: Install the arm cylinder in pin hole A for the WORK position. Install the arm cylinder in pin hole B for lower transport height. IMPORTANT: When moving the bucket into the TRANSPORT position, be very careful that you do not damage the cab. The bucket can contact the cab when the arm cylinder is installed in pin hole B. Do not work the machine when in the TRANSPORT position. Damage to the arm can occur.
130
