CONTROLS/INSTRUMENTS/ACCESSORIES
FUEL TANK FILLER PUMP (optional) Template Name: OM_1_col Template Date: 1994_04_29
WARNING : Never refuel when the engine is running. Never smoke while refuelling. IMPORTANT : This pump is in the tool box and should be used only for fuel.
STEP 3
1
STEP 1 Park the machine on flat, level ground. Stop the engine and remove the starter switch key. STEP 2
PDF0361
TRIM THIS EDGE
Measure the height of the drum and place the sight ring (1) on the suction tube at a height slightly lower than that of the drum. STEP 4 PE11716
Alt= to hide template information Alt+ to display template information
Remove the filler cap from the fuel tank. WARNING : It is essential to remove the filler cap before refilling the tank, since this will prevent any possibility of an accident when opening the filler cap after filling. PDF0362
Make sure that the screen on the end of the suction hose is correctly attached and then lower the suction hose into the drum.
96
