CONTROLS/INSTRUMENTS/ACCESSORIES
IMPORTANT : Do not operate the machine without the lower panels correctly in place. WARNING : Before travel, make sure the doors are properly closed. PH08008
RIGHT-HAND SIDE PANEL
NOTE : Use the starter switch key to lock the door. WARNING : Before travel, make sure the side door is properly closed.
TRIM THIS EDGE
WARNING : Never leave tools or other objects inside the air intake compartment.
Alt= to hide template information Alt+ to display template information
Remove the side panel retaining screws and remove the side panels.
PH07831
Template Name: OM_1_col Template Date: 1994_04_29
The right-hand side panel gives access to the walkway, the radiator and the oil cooler.
87
