CONTROLS/INSTRUMENTS/ACCESSORIES
WINDSHIELD
Opening STEP 1
PH08302
IMPORTANT : Make sure that the windshield is correctly locked.
Closing PE08220
Pull the two handles inward to unlock the windshield and pull backward.
STEP 1
STEP 2
PH08302
Pull the two handles inward to unlock the windshield and pull forward. PH07901
Using the handles, bring the windshield into horizontal position.
75
TRIM THIS EDGE
RIGHT PAGE
TRIM THIS EDGE
Pull the windshield completely to the rear and then push the two handles outwards so as to lock the windshield in position.
Alt= to hide template information Alt+ to display template information
STEP 3
Template Name: OM_1_col Template Date: 1994_04_29
IMPORTANT : Before opening the windshield, make sure that the windshield wiper is pressing against the windscreen and that the front and rear view mirrors are not folded back against the windscreen.
