CONTROLS/INSTRUMENTS/ACCESSORIES
CAB DOOR Template Name: OM_1_col Template Date: 1994_04_29
1
2
2
PG02207
PH07711
The door is opened with the handle (1) . It can be kept open with the latch (2).
To unlatch the door, tilt the lever upwards. NOTE : Use the starter switch key to lock the door.
TRIM THIS EDGE
IMPORTANT : Whenever undertaking any road travel, it is imperative for the cab door to be properly closed and fastened. WARNING : Do not leave the door ajar. Fasten it securely in the open or closed position.
Alt= to hide template information Alt+ to display template information
WARNING : When seated in the operator’s compartment take care not to operate accidentally the left-hand control lever when releasing the door. To avoid any danger, place the left-hand control arm in the raised position. See “Left-hand control arm”.
36
