CHECKING FOR CYLINDER LEAKAGE Template Name: OM_1_col Template Date: 1994_04_29
A cylinder rod should be slightly oily. Check that there are no leaks after a period of work, when the whole hydraulic system is at normal operating temperature. 1. Wipe clean the rod and bearing on the cylinder to be checked. 2. Operate normally for five to ten minutes. 3. Extend the cylinder rod. 4. Check that there are no leaks.
TRIM THIS EDGE
ROD APPEARANCE
TEST
CONCLUSION
Dry
Slight traces of oil when a piece of paper is wiped over 20 cm of the rod.
Normal
Slightly oily
Paper remains stuck to rod when run over the rod.
Normal
Oily
Paper remains stuck when placed on the rod.
Normal
Very oily or weeping
Each time cylinder rod is extended, a ring of oil can be seen on the rod.
Leakage
Each time the rod retracts, the excess oil drips from the gland.
