LUBRICATION/FILTERS/FLUIDS
Bleeding the system
STEP 4
- One 17 mm wrench for hexagonal head screws It is necessary to bleed the fuel system when :
PH08320
Install the new filters. Turn the filters until the seals are in contact with the filter heads and tighten the filters by hand, half a turn more.
- The tank has been completely emptied. - Parts of the fuel system have been removed for servicing or repair work. - The machine has been in storage for a fairly long period. STEP 1
TRIM THIS EDGE
IMPORTANT : Do not use a filter wrench. Overtightening can damage the seals and filters. STEP 5
Alt= to hide template information Alt+ to display template information
Tools required
PG03320
STEP 2 PH08314
Loosen the clamps and remove the filter and hoses. Install a new filter and tighten the clamps. NOTE : If the engine does not regain full power after replacing the filters, bleed the circuit.
PG03320
Operate the priming pump until fuel flows out with no air bubbles in it. Then tighten the bleed fitting. 181
TRIM THIS EDGE
RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
Loosen the bleed fitting two or three turns.
