JOB SITE AND ROAD OPERATION
LOAD HANDLING Template Name: OM_1_col Template Date: 1994_04_29
WARNING : To use this machine for lifting a load make sure that the machine is suitable for performing that type of work. In this event, it is mandatory for the machine to be equipped with safety valves, an overload indicator, a load handling chart corresponding to the type of machine and to its attachment, plus a load fixing point. WARNING : Always operate on firm, flat ground, away from any obstacles. Check that the load is stable a few centimeters from the ground before lifting it to any height. Movements must be safe and smooth when handling loads. Moving quickly does not mean moving in a violent manner. When travelling with a load, always comply with the following instructions : TRIM THIS EDGE
- Place the upperstructure in line with the undercarriage. - Bring the load as near as possible to the undercarriage and ground. - It is mandatory to travel at slow speed, using the travel control lever and with the front axle unlocked.
What to do in the event of a hydraulic system failure
Alt= to hide template information Alt+ to display template information
Stop the engine immediately. Hold the control lever(s) in the position necessary for the attachment to be lowered as required and operate the emergency pump until the load is resting on the ground.
(1188 Series) Tools required - One 13 mm wrench for hexagonal head screws. If it is not possible to lower the attachment, a burst pipe or hose in the pilot circuit may be the cause of the problem. In that case it will be necessary to operate on one of the two boom cylinder safety valves to enable the attachment to be lowered.
144
