CONTROLS/INSTRUMENTS/ACCESSORIES To remove the side panels, remove the retaining screws.
Template Name: OM_1_col Template Date: 1994_04_29
IMPORTANT: Do not operate the machine if the side panels have been removed.
!
WARNING: Before travelling, make sure the access panels are fastened in place.
PH08008
RIGHT-HAND SIDE DOOR 788 Series
988 Series
TRIM THIS EDGE
Alt= to hide template information Alt+ to display template information
CD98J001
CD98D020
The right-hand door provides access to the walkway, the radiator, the oil cooler and the batteries.
!
The right-hand door provides access to the radiator and oil cooler.
WARNING: Never leave tools or other items inside the air intake compartment.
NOTE: Use the starter switch key to lock the side door.
!
WARNING: Before travelling, make sure the side door is securely latched.
92
