CONTROLS/INSTRUMENTS/ACCESSORIES
ACCESS PANELS
The access panels must be removed to perform service work.
PG02727
To remove the center panel, release the lever located in the panel hole and pull the panel backwards.
Center panel
Side panels
PH08006
PH08003
The center panel provides access mainly to the engine components.
The left-hand panel provides access to the anti-surge valve and to the hydraulic reservoir shut-off valve and drain plugs.
91
TRIM THIS EDGE
RIGHT PAGE
TRIM THIS EDGE
PH07303
For better access to components, place the upperstructure at right angles to the undercarriage.
Template Name: OM_1_col Template Date: 1994_04_29
- One 17 mm wrench for hexagonal head screws
Alt= to hide template information Alt+ to display template information
Tools required
