STORAGE
STORING THE MACHINE
STORAGE
Template Name: OM_1_col Template Date: 1994_04_29
The following procedure applies when the machine is to be stored for one month or more.
Preparation for storage 1.
Park the machine on a flat, horizontal and clean surface.
2.
Lubricate the machine at all grease points.
3.
Retract the dipper cylinder rod completely.
4.
Lubricate the exposed surfaces of the cylinder rods or protect the cylinder rods by applying a protective film (aerosol spray part no. S1403568).
NOTE: When using the machine after storage, the protective film will be naturally eliminated.
TRIM THIS EDGE
5.
Release the pressure in the hydraulic system.
6.
Clean all outer engine components with diesel fuel.
7.
While the engine is still warm, drain the oil from the crankcase and fill with anticorrosive oil up to the MAX mark on the dipstick.
8.
Drain the fuel tank and fill it with a solution of 90% diesel fuel and 10% anticorrosive oil.
9.
Run the engine at idle speed for five minutes until the anticorrosive oil has reached the lines and hoses, the filters, the pump, the turbocharger and the injectors.
Alt= to hide template information Alt+ to display template information
10. Remove the rocker arm covers. Spray a solution of 90% diesel fuel and 10% anticorrosive oil into the rocker arm chamber. Install the rocker arm covers. 11. Plug the air filter intake and the exhaust pipe outlet. 12. Disconnect the electrical circuit using the battery master switch. 13. Remove the batteries.
318
