MAINTENANCE/ADJUSTMENTS
CD98D034
Start the engine and retract the bucket cylinder. STEP 6
CD98D033
Using the screwdriver, remove the split pin from the bucket/dipper linkage pin. Then remove the bucket/dipper linkage pin.
TRIM THIS EDGE
STEP 8
Alt= to hide template information Alt+ to display template information
STEP 7
STEP 5
CD98D034
CD98D032
Start the engine. Operate the attachment controls so as to disengage the dipper from the bucket.
!
WARNING: The tube installed to block the bucket ejector must never be removed when the bucket is in storage.
IMPORTANT: The ejector must be blocked whenever the bucket is transported or handled.
283
TRIM THIS EDGE
RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
Raise the attachment so that the bucket stabilizes. Rest the bucket on the ground. Stop the engine and remove the starter switch key.
