OPERATING INSTRUCTIONS STEP 4
STEP 2
Template Name: OM_1_col Template Date: 1994_04_29
Raise the cab carefully and position it correctly on the cab floor. IMPORTANT: Make sure that the seal located at the back of the cab is correctly in place. STEP 3
PH07911
Reconnect the electrical power point to its base after removing the protective cap. Reconnect the windshield washer hose. Reconnect the radio aerial (if equipped). STEP 5
TRIM THIS EDGE
PH07911
Alt= to hide template information Alt+ to display template information
PH07909
Install the trim. PH00305
Install and tighten the four cab mounting screws to a torque of 120 Nm and reposition the floor cover correctly at the front of the operator’s compartment.
134
