LOAD HANDLING LIMITS Template Name: OM_1_col Template Date: 1994_04_29
The load handling chart shows the different authorized loads which can be lifted at different reach points, depending on the type of attachment installed on the machine. The machine must be on flat, firm, level ground with the front axle locked. The stabilizers and the dozer blade (if equipped) must be resting on the ground. Loads are given in daN (1daN = 1.02 kg), for a machine without tool, with the bucket cylinder rod completely retracted, for full upperstructure swing, with a safety margin factor: - of 33% based on stability
TRIM THIS EDGE
- of 15% based on hydraulic capacity CS98F554
with the end of the dipper as the load fixing point.
Alt= to hide template information Alt+ to display template information
If the load fixing point is the connecting rod/bucket linkage pin or the eye located on the Quick Coupler (if equipped), the weight of the Quick Coupler (if equipped) (weight indicated on the manufacturer’s plate) and the weight of the bucket, if installed on the machine or on the Quick Coupler, must be subtracted from the values given in the chart. See “Buckets” in the “Specifications” Section. The reach is given from the machine’s swing axis and the height is taken from the load fixing point. NOTE: The loads given are valid for the full working range height at the reach point indicated.
